Reusable break away valve for fuel dispenser

FOB Reference Price:Get Latest Price
$25.00 - $30.00 / Piece | 1 Piece/Pieces (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
COWELL
Model Number:
MD-15
Product name:
Breakaway valve
Diameter:
3/4"
Application:
fuel oil
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Carton
Port
shanghai
Lead Time :
7days



 MD-15 Breakaway



Description:



CW-15 breakaway is reconnectable for the conventional dispensing market. It is designed to be

installed on fuel dispensing hoses, and will separate when subjected to a designated pull force.

The dual valves seat automatically stopping the flow of fuel and limiting any fuel spillage, while

protecting the dispensing equipment. When reconnecting the separate halves, the seals tightly

on an O-ring before the poppet stems engage to open the valve. For proper operation on high-

hanging hoses, the breakaway must always be installed with straightening hose with a minimum

length of 9”. For low hose applications, it should be installed down-stream of retractor cable.



Materials:



Body: Die Cast Zinc

Main Seals: Viton

Main Spring: Stainless Steel

Guide & Poppet: POM

Protective Sleeve: PA66



Technical Specification

  Inlet:

BSPF/NPT ¾”

  Outlet:

BSPF/NPT ¾”



Feature & Benefits:



Pull force: with a pull force of 250lbs±5%
Unique double-poppet design: with low pressure drop
Flow rate: 0-60L/Min
Working Pressure: 0.18Mpa
Coupling halves: protected by proven plastic sleeves

  Easily reconnected: Just “push and twist” until you hear

  an audible click, signifying the unit has been correctly

  reconnected. Reconnection force approximately 15lbs

Line shock: It is able to absorb the effects of normal line

  shock through the unique design of the disconnecting

  features.









Warranty: the product is guaranteed for 12 months from the date of delivery under normal condition.Customers will enjoy free repair services for failures found within the warranty due to manufacturing quality;We provide paid repair services for products damages not arising from manufacturing quality issues or not within the scope of warranty.
