Cowell stainless steel impeller corrosion Chemical centrifugal pump

FOB Reference Price:Get Latest Price
$500.00 - $8,000.00 / Set | 1 Set/Sets (Min. Order)
Maximum Head:
132m
Maximum Flow Rate:
2900r/min
Horsepower:
0.55KW~160KW
Shipping:
Support Sea freight
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Shanghai, China
Brand Name:
cowell
Model Number:
KIH
Structure:
Single-stage Pump
Pressure:
Low Pressure
Product name:
centrifugal pump
Head:
3.6~132m
Rotate speed:
1450r/min, 2900r/min
Power of motor:
0.55KW~160KW
lnlet/Outlet:
25~250mm
Temperature:
-40°C~+180°C
Working pressure:
less than 1 .6MPa
Usage:
Water
Application:
Sewage
Power:
Electric
Fuel:
Diesel
Packaging & Delivery
Packaging Details
wooden case for stainless steel impeller corrosion Chemical centrifugal pump
Port
Shanghai or Ningbo
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 10 To be negotiated



_01

KIH pump centrifugal pump Chemical pump Corrosion pump

Main Characteristics:
KIH type pump not just absorbed the abroad'advanced chemical pump design concept, but also increased the
independent innovation. The KIH pump has a strengthen degine in the pump body and suspended frame,
making it better in appearance, safe and reliable operation, and also has a longer life.

Suspension cross sery products have an outstanding design for heat sink and also increase the cooling
devices, which ensures to meet different and complexed requirements of indust rial and mining projects, and
also accelerates the delivery and inventory.



According to customers 'actual requirments, the pump'shaft s ealing can be divided into packing seal, packing
seal with outside washing, single face unbalanced seal, single face unbalanced seal with outside washing,
double face unbalanced seal, double face unbalanced seal with outside washing, single face balanced seal,
single face balanced seal with outside washing, double face balanced seal, double face balanced seal with
outside washing, dynamic seal, external mounted seal, and special seal, etc. Under different industrial and
mining conditons, we would choose suitable sealing structures to make sure that the sealing is used safely,
reliable and has a longer life. If there is norequirment, we qould choose the standard single face unbalance
sealing structure.



The standard configuration of couplings is three stage uninstalled couplings. This design makes aure that there
is no need to remove inle and oulet connection line, body of the pump and the enginee if maintenance is
nessisary. The connection types are short sub type, direct connection type and diaphragm type.



The impeller of pump body is precision casting and the efficiency is higher than IH pump. The impeller has
closed type, semi—open type and open type.



The material for flow passaged components is stainless steel 304, and other optional materials are 304 L, 316,
31 6 L, CD—4 MCu, 904, 904 L, and hastelloy etc. mainteniance cost and maintenance difficulty greatly.



Main usage:
Mainly used in industrial departments, like chemical, petroleum, petrochemical industry, metallurgy, light
industry, printing, dyeing, pharmaceutical, environmental protection, sea water desalination, maritime oil,
papermaking, foodstuff, etc. Mainly used in organic or inorganic chemical medium, oil products and corrosive
liquid which doesn't contain solid particles.



 Technical Specification

 Capacity

 3.4~600m³/h

 Inlet/Outlet

 25~250mm

 Head

 3.6~132m

 Rotate speed

 1450r/min, 2900r/min

 Power of motor

 0.55KW~160KW

 Density

 P=1.0~1 .84 x 103kg/m³

 Temperature  -40°C~+180°C
 Working pressure Less than 1.6MPa
